Narrowboat Doors

Narrowboat Doors

Narrowboat doors are manufactured with security in mind.

Upvc narrowboat doors are double glazed and come with toughened security glass as standard. We install multipoint locking system with a 3 star security cylinder for additional peace of mind that you are safe on your narrowboat.

Manufactured using slim odd leg upvc frame, our narrowboat door offer addition features such as being weather tight, maintenance free and easy to adjust with fully adjustable hinges.

Learn more and obtain a hassle free quotation today.

  • Single Door

  • Double Door

  • Swan Hatch

  • Door Combination

  • Door & Hatch

  • Shaped Door

Narrowboat Doors

Narrowboat Doors - Upvc Double Glazed Narrowboat Doors

Our Upvc Boat Doors are double glazed and come with toughened security glass as standard.

  • Maintenance Free.
  • 3* Security Cylinder.
  • Multi point locking system.
  • Double glazed security glass.
  • Fully adjustable hinges.
  • Odd Leg Frame - This frame has a 20mm external lip / flange, which allows for coverage and covers the outside face of the property.

Our products are manufactured to order. Our manufacturing time for white windows / doors are within 4 weeks & painted windows 6 weeks from order confirmation.


Always measure from inside.

Remove any internal trim around the door to reveal the existing door frame. Simply measure the existing door. If the existing door is a very tight fit, reduce the overall hole size by 5mm to allow for easy installation.

Out boat doors can be installed directly in an existing timber frame.

Do not worry if you have rounded corners, these can easily squared off using a hand held oscillating saw. The corners do not need to be 'professionally squared' as the external overlap of the upvc door frame will cover the corners and therefore will not be seen.

Measuring Guide


Screw Fix: If your wall construction differs than the above wall thickness, or you'd prefer to trim the internal surround of the window with the existing timber or an new timber beading then you can fix them using screw fix through the depth of the window frame into the timber subframe of the window. Simply open the vent and screw through the frame.

You will need to seal the frame with non drying sealant silicone. As the boat is constantly moving, if you use standard silicone, it will crack and leak over time. You can also use a neoprene foam tape.

Glaze the door and toe and heel. There are adjustments on the hinge should you need.

  • Neoprene

  • Neoprene - Silicone

  • Silicone

Narrowboat Door Colour Options

Unlike our slimline double glazed narrowboat windows. Our narrowboat doors are available in a wider range of colour finishes.

The doors are available with the same colour external or internal. Or colour external on white internal.
